Glass fiber optics WRB
WRB 2-2000 S-90-4.0-2.5
Article Number: 205621
Our product portfolio of fiber optics includes high-quality fibers for large ranges, a high mechanical load and high temperatures.
- High-quality glass fibers
- Resistant to high temperatures
- Robust, highly flexible
Your price: Login
Length
2,000 mm
Dimension fiber bundle
Ø 2.5 mm
Housing length
15 mm
Light aperture
radial
Mounting diameter
Ø 8 mm
Bending radius
> 3 x tube-Ø
Material of fiber
Glass fibers
Material
- Stainless steel (Sensor probe)
- Silicone-metal sleeve (Coating)
Operating principle
Diffuse sensor
Design
Cylinder
Single fiber
Ø 0.05 mm
To be used for
Amplifiers for glass fiber optics
Opening angle
67°
Scanning range
80 mm
Temperature resistance
-40 … +180 °C (temporarily up to +250 °C)
Protection type
IP 67
