SBP-FK Fixed Color
SBP-FK-R50D-1B-2M
Article Number: 214543
The dome-shaped, multicolor 1-segment signal lamps from the SBP-FK series offer an efficient solution for many applications. They are available in three variantsand enable flexible signaling: as a standard variant for visual signaling, with an additional buzzer for audible support and a Touch button for pick-to-light and user guidance systems. Thanks to directly controlled multicolor LEDs, the signal lamps display up to 7 colors with 24V power, offering a clear and reliable display.
- 7 colors displayed with 24V power
- Industry-ready
- Control via shared 24V power or shared ground
- Clearly audible acoustic signal
Your price: Login
Service voltage
24 V DC
Internal power consumption
57 mA (24 V DC)
Power
1.4 W (24 V)
Inverse polarity protection
Yes
Illuminated area
50 x 20 mm (Ø x H)
Number of segments
1
Housing material
Plastic (ABS)
Material
PC, dome-shaped (Diffusor)
Weight
161 g
Protection class
III
Approvals
UL
Design
Dome
Product series
SBP-FK Fixed Color
Buzzer
With buzzer, 90 (dB(A) typ. @ 50 cm)
Scope of delivery
Mounting bracket
Trigger input buzzer (high/low)
24 V / 0V (1x)
Interface
24 V DC
Base color
Red, green, blue (RGB)
Displayable colors
Red, green, yellow, blue, white, pink, cyan
Vibration load
10 to 55 Hz / 1.0 mm / 30 g / 11 ms
Ambient temperature during operation
0 … +50 °C
Protection type
IP 20
Connection
Cable, 2.0 m
